Wichard Mxevo Block
Pickup available at Arthur Beale Warehouse
Usually ready in 2 hours
Wichard Mxevo Block
10 mm / 8 mm Allen Pin
Arthur Beale Warehouse
Pickup available, usually ready in 2 hours
Severalles Farm
Ilmer
Princes Risborough HP27 9QZ
United Kingdom
MXEvo is the new generation of one-piece blocks developed by Wichard. Two versions are available: standard captive pin and allen head pin. Each version exists in three sizes.
Main MXEvo features:
- Dedicated to heavy load applications
- Impressive working and breaking load limits
- Captive pin on the standard version
- Becket function to make tackles
- Rope kept on track thanks to the fins
- Optimized weight and dimensions
- Easy opening – Easy rope installation
- Two versions existing in three sizes
- Limited rope wear thanks to the track conception
- Monobloc item (without mechanical part) for a better reliability
- For ropes from 8 to 14mm
| Description | Length | Width | Ø | A | B | ØC | Work Load | Break Load | Weight |
| Captive Pin - for max rope size 8 mm | 53 mm | 26 mm | 6 mm | 18 mm | 13 mm | 7 mm | 1040 kg | 2300 kg | 0.053 kg |
| Captive Pin - for max rope size 10 mm | 62 mm | 36 mm | 8 mm | 18 mm | 18 mm | 9 mm | 1760 kg | 4100 kg | 0.109 kg |
| Captive Pin - for max rope size 14 mm | 77 mm | 44 mm | 10 mm | 22 mm | 22 mm | 11 mm | 2640 kg | 6000 kg | 0.222 kg |
| Allen Pin - for max rope size 8 mm | 53 mm | 26 mm | 6 mm | 18 mm | 13 mm | 7 mm | 720 kg | 1700 kg | 0.048 kg |
| Allen Pin - for max rope size 10 mm | 62 mm | 36 mm | 8 mm | 18 mm | 18 mm | 9 mm | 1300 kg | 3500 kg | 0.1 kg |
Downloads
